Aviation Product: Variable Height UCAS XS Access Platform 1.75m – 2.5m (towable)

H1.75-2.2m - L0.75 - W0.5 | Mid-platform H1.5m | Easy tow robust all wheel suspension chassis

Part No: 812.350.05
  • E145-175 full access with one towable platform
  • Ideal platform for engine access on wide bodied aircraft
  • Easy tow robust all wheel suspension chassis
  • Slip resistant self-draining tread steps & platform
  • Platform edge & railing protective "soft" padding
  • Excellent through life costs
Compatible with...

Variable Height UCAS XS Access Platform 1.75m – 2.5m (towable) is compatible with:

A330 / B757 / B767 / B787 / Embraer 145 / Embraer 175

The UCAS XS has been designed for ramp and airport environment requirements

Designed for accessing engine & service and inspection points in and around B757-767 Embraer 145-175 aircraft.

The UCAS XS has been designed for ramp and airport environment requirements with a robust chassis incorporates all wheel suspension, proven slew ring steering and safe wheel brake parking with tow bar in vertical position.

The lightweight aluminium construction provides ease of manoeuvring with slip resistant, self-draining tread for stairs and platform.

The variable height platform system incorporates a dog rack and lock safety system which is sprung loaded ensuring each incremental increase 50mm (2inch) in height is locked out, with an easy wind cable on a drum height raise from 1,750-2,250mm.

Front platform with half height folding side railings with opening front gates (3 lock positions) provides a multiple use safe working platform providing safe access to engines, wing & service points.

Safe working heights mid platform 600mm with Variable height platform of 1.75-2.25m height.

812.350.05_UCAS XS

See the UCAS XS platform being demonstrated at MRO Americas

Watch the video opposite to see Will McOnie of Semmco Inc. demonstrating the Variable Height Under Cowl Access Steps 1.75m – 2.5m (towable) UCAS XS at MRO Americas in 2019.

Also shown is the SMART Nitrogen Trolley, also available as an Oxygen version.

Video Credit: MRO Network – MRO Americas 2019
